MAX3679A

+3.3V, Low-Jitter Crystal to LVPECL
Clock Generator

2

_______________________________________________________________________________________

ABSOLUTE MAXIMUM RATINGS

ELECTRICAL CHARACTERISTICS

(V

CC

= +3.0V to +3.6V, T

A

= -40°C to +85°C, unless otherwise noted. Typical values are at V

CC

= +3.3V, T

A

= +25°C, unless other-

wise noted.) (Notes 1, 2, and 3)

Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and functional
operation of the device at these or any other conditions beyond those indicated in the operational sections of the specifications is not implied. Exposure to
absolute maximum rating conditions for extended periods may affect device reliability.

Supply Voltage Range V

CC

, V

CCA

,

V

DDO_A

, V

CCO_A

, V

CCO_B

................................-0.3V to +4.0V

Voltage Range at REF_IN, IN_SEL,

SELA[1:0], SELB[1:0], RES[1:0],
QAC_OE, QA_OE, QB0_OE, QB1_OE,
MR, BYPASS ..........................................-0.3V to (V

CC

+ 0.3V)

Voltage Range at X_IN Pin ...................................-0.3V to +1.2V

Voltage Range at GNDO_A...................................-0.3V to +0.3V
Voltage Range at X_OUT ............................-0.3V to (V

CC

- 0.6V)

Current into QA_C ...........................................................±50mA
Current into QA, QA, QB0, QB0, QB1, QB1 .....................-56mA
Continuous Power Dissipation (T

A

= +70

°C)

32-Pin TQFN (derate 34.5mW/

°C above +70°C) .......2759mW

Operating Junction Temperature Range ...........-55°C to +150°C
Storage Temperature Range .............................-65°C to +160°C

PARAMETER

SYMBOL

CONDITIONS

MIN

TYP

MAX

UNITS

Power-Supply Current

I

CC

(Note

4)

77 100 mA

CONTROL INPUT CHARACTERISTICS
(SELA[1:0], SELB[1:0], IN_SEL, QAC_OE, QA_OE, QB1_OE, QB0_OE, MR,

BYPASS Pins)

Input Capacitance

C

IN

2

pF

Input Pulldown Resistor

R

PULLDOWN

Pin MR

75

k

Input Logic Bias Resistor

R

BIAS

Pins SELA[1:0], SELB[1:0], QB0_OE

50

k

Input Pullup Resistor

R

PULLUP

Pins QAC_OE, QA_OE, QB1_OE, IN_SEL,
BYPASS

75 k

LVPECL OUTPUT SPECIFICATIONS (QA,

QA, QB0, QB0, QB1, QB1 Pins)

T

A

= 0°C to +85°C

V

CC

-

1.13

V

CC

-

0.98

V

CC

-

0.83

Output High Voltage

V

OH

T

A

= -40°C to 0°C

V

CC

-

1.18

V

CC

-

0.83

V

T

A

= 0°C to +85°C

V

CC

-

1.85

V

CC

-

1.7

V

CC

-

1.55

Output Low Voltage

V

OL

T

A

= -40°C to 0°C

V

CC

-

1.90

V

CC

-

1.55

V

Peak-to-Peak Output-Voltage
Swing (Single-Ended)

(Note

2)

0.6

0.72

0.9

V

P-P

Clock Output Rise/Fall Time

20% to 80% (Note 2)

200

350

600

ps

PLL enabled

48

50

52

Output Duty-Cycle Distortion

PLL bypassed (Note 5)

40

50

60

%

LVCMOS/LVTTL INPUT SPECIFICATIONS
(SELA[1:0], SELB[1:0], IN_SEL, QAC_OE, QA_OE, QB1_OE, QB0_OE, MR,

BYPASS Pins)

Input-Voltage High

V

IH

2.0

V

Input-Voltage Low

V

IL

0.8

V
