DS1202, DS1202S
032697 6/11
ABSOLUTE MAXIMUM RATINGS*
Voltage on Any Pin Relative to Ground –0.3V to +7.0V
Operating Temperature 0 ° C to 70 ° C
Storage Temperature –55 ° C to +125 ° C
Soldering Temperature 260 ° C for 10 seconds
* This is a stress rating only and functional operation of the device at these or any other conditions above those
indicated in the operation sections of this specification is not implied. Exposure to absolute maximum rating
conditions for extended periods of time may affect reliability.
RECOMMENDED DC OPERATING CONDITIONS (0
°
C to 70
°
C)
PARAMETER SYMBOL MIN TYP MAX UNITS NOTES
Supply Voltage V
CC
2.0 5.5 V 1
Logic 1 Input V
IH
2.0 V
CC
+0.3 V 1
Logic 0 Input V
IL
V
CC
=2.0V –0.3 +0.3
V 1 Logic 0 Input V
IL
V
CC
=5V –0.3 +0.8
V 1
DC ELECTRICAL CHARACTERISTICS (0
°
C to 70
°
C; V
CC
= 2.0 to 5.5V*)
PARAMETER SYMBOL MIN TYP MAX UNITS NOTES
Input Leakage I
LI
+500 µ A 6
I/O Leakage I
LO
+500 µ A 6
Logic 1 Output V
OH
V
CC
=2V 1.6
V 2 Logic 1 Output V
OH
V
CC
=5V 2.4
V 2
Logic 0 Output V
OL
V
CC
=2V 0.4
V 3 Logic 0 Output V
OL
V
CC
=5V 0.4
V 3
Active Supply Current I
CC
V
CC
=2V 0.4
mA 5 Active Supply Current I
CC
V
CC
=5V 1.2
mA 5
Timekeeping Current I
CC1
V
CC
=2V 0.3
µ A 4 Timekeeping Current I
CC1
V
CC
=5V 1
µ A 4
Leakage Current I
CC2
V
CC
=2V 100
nA 10 Leakage Current I
CC2
V
CC
=5V 100
nA 10
*Unless otherwise noted.
CAPACITANCE (t
A
= 25
°
C)
PARAMETER SYMBOL CONDITION TYP MAX UNITS NOTES
Input Capacitance C
I
5 pF
I/O Capacitance C
I/O
10 pF
Crystal Capacitance C
X
6 pF
