DS1672
4 of 12
AC ELECTRICAL CHARACTERISTICS
(V
CC
> V
CCMIN
, T
A
= -40 °C to +85°C)
PARAMETER SYMBOL CONDITION MIN TYP MAX UNITS NOTES
Fast Mode 100 400
SCL Clock
Frequency
f
SCL
Standard Mode 100
kHz
Fast Mode 1.3
Bus Free Time
Between a STOP and
START Condition
t
BUF
Standard Mode 4.7
ms
Fast Mode 0.6
Hold Time
(Repeated) START
Condition
t
HD:STA
Standard Mode 4.0
ms 6
Fast Mode 1.3
LOW Period of SCL
Clock
t
LOW Standard Mode 4.7
ms
Fast Mode 0.6
HIGH Period of SCL
Clock
t
HIGH
Standard Mode 4.0
ms
Fast Mode 0.6
Setup Time for a
Repeated START
Condition
t
SU:STA
Standard Mode 4.7
ms
Fast Mode 0 0.9
Data Hold Time t
HD:DAT
Standard Mode 0
ms 7, 8
Fast Mode 100
Data Setup Time t
SU:DAT
Standard Mode 250
ns 9
Fast Mode 20 + 0.1C
B
300
Rise Time of Both
SDA and SCL
Signals
t
R
Standard Mode 1000
ns 10
Fast Mode 20 + 0.1C
B
300
Fall Time of Both
SDA and SCL
Signals
t
F
Standard Mode 300
ns 10
Fast Mode 0.6
Setup Time for STOP
Condition
t
SU:STO
Standard Mode 4.0
ms
Capacitive Load for
Each Bus Line
C
B
400 pF 10
I/O Capacitance C
I/O
10 pF
Note 6: After this period, the first clock pulse is generated.
Note 7: A device must internally provide a hold time of at least 300ns for the SDA signal (referenced to the V
IHMIN
of the SCL signal) in order to
bridge the undefined region of the falling edge of SCL.
Note 8:The maximum t
HD:DAT
has only to be met if the device does not stretch the LOW period (t
LOW
) of the SCL signal.
Note 9: A fast mode device can be used in a standard mode system, but the requirement t
SU:DAT
>= to 250ns must then be met. This will
automatically be the case if the device does not stretch the LOW period of the SCL signal. If such a device does stretch the LOW
period of the SCL signal, it must output the next data bit to the SDA line t
R
max + t
SU:DAT
= 1000 + 250 = 1250ns before the SCL line is
released.
Note 10: C
B
– Total capacitance of one bus line in pF.
