The DY/DT bits (bit 6 of the alarm day/date registers)
control whether the alarm value stored in bits 0 to 5 of
that register reflects the day of the week or the date of
the month. If DY/DT is written to logic 0, the alarm is the
result of a match with date of the month. If DY/DT is
written to a logic 1, the alarm is the result of a match
with day of the week.

When the RTC register values match alarm register set-
tings, the alarm-flag (AF) bit is set to logic 1. If the
alarm-interrupt enable (AIE) is also set to logic 1 and
the INTCN bit is set to logic 1, the alarm condition acti-
vates the SQW/INT signal.

Since the contents of register 08h are expected to nor-
mally contain a match value of 00–99 decimal, the
codes F[0–9], and FF have been used to tell the part to
mask the tenths or hundredths of seconds accordingly.

Power-Up/Down, Reset, and

Pushbutton Reset Functions

A precision temperature-compensated reference and
comparator circuit monitors the status of V

CC

. When an

out-of-tolerance condition occurs, an internal power-fail
signal is generated that blocks read/write access to the
device and forces the RST pin (DS1391/DS1393 only)
low. When V

CC

returns to an in-tolerance condition, the

internal power-fail signal is held active for t

RST

to allow

the power supply to stabilize, and the RST (DS1391/
DS1393 only) pin is held low. If the EOSC bit is set to
logic 1 (to disable the oscillator in battery-backup
mode), the internal power-fail signal and the RST pin is
kept active for t

RST

plus the startup time of the oscillator.

The DS1391/DS1393 provide for a pushbutton switch to
be connected to the RST output pin. When the
DS1391/DS1393 are not in a reset cycle, it continuously
monitors the RST signal for a low-going edge. If an
edge is detected, the part debounces the switch by
pulling the RST pin low and inhibits read/write access.
After PB

DB

has expired, the part continues to monitor

the RST line. If the line is still low, it continues to monitor
the line looking for a rising edge. Upon detecting
release, the part forces the RST pin low and holds it low
for an additional PB

DB

.

DS1390/DS1391/DS1392/DS1393

Low-Voltage SPI/3-Wire RTCs with

Trickle Charger

____________________________________________________________________

15
