32
ATF2500CQL
0777G–12/01
Packaging Information
40D6 – Cerdip
53.09(2.090)
51.82(2.040) PIN
1
15.49(0.610)
12.95(0.510)
0.127(0.005)MIN
1.78(0.070)
0.38(0.015)
0.66(0.026)
0.36(0.014)
1.65(0.065)
1.14(0.045)
15.70(0.620)
15.00(0.590)
17.80(0.700) MAX
0.46(0.018)
0.20(0.008)
2.54(0.100)BSC
5.08(0.200)
3.18(0.125)
SEATING
PLANE
5.72(0.225)
MAX
48.26(1.900) REF
0º~ 15º REF
Dimension in Millimeters and (Inches)
Controlling dimension: Inches
04/11/01
2325 Orchard Parkway
San Jose, CA 95131
TITLE DRAWING NO.
R
REV.
40D6, 40-lead (0.600" Wide), Non-windowed, Ceramic Dual Inline
Package (Cerdip)
A 40D6
MIL-STD-1835 D-5 CONFIG A (Glass Sealed)
