DS1615 ALARM TIME STAMPS AND DURATIONS Figure 2c
Sample Counter Address
(Low, Medium, High Bytes)
Duration
Address
Register
220, 221, 222 223 T1 Low
224, 225, 226 227 T2 Low
228, 229, 22A 22B T3 Low
22C, 22D, 22E 22F T4 Low
230, 231, 232 233 T5 Low
234, 235, 236 237 T6 Low
238, 239, 23A 23B T7 Low
23C, 23D, 23E 23F T8 Low
240, 241, 242 243 T9 Low
244, 245, 246 247 T10 Low
248, 249, 24A 24B T11 Low
24C, 24D, 243 24F T12 Low
250, 251, 252 253 T1 High
254, 255, 256 257 T2 High
258, 259, 25A 25B T3 High
25C, 25D, 25E 25F T4 High
260, 261, 262 263 T5 High
264, 265, 266 267 T6 High
268, 269, 26A 26B T7 High
26C, 26D, 26E 26F T8 High
270, 271, 272 273 T9 High
274, 275, 276 277 T10 High
278, 279, 27A 27B T11 High
27C, 27D, 27E 27F T12 High
DS1615 HISTOGRAM MEMORY Figure 2d
Address (Low – High Byte) Register
800 – 801 -40, -39.5, -39, -38.5°C Data Bin
802 – 803 -38, -37.5, -37, -36.5°C Data Bin
804
↓
87B
↓
87C – 87D 84, 84.5, 85°C Data Bin
