DS1615

11 of 24

starts a datalog mission or polls the device for information, one or both of these pins will be pulsed four
times. Depending on the status of the device, both pins will be pulsed simultaneously or just one pin will
be pulsed at a time. Each pulse is 62.5 ms in duration and will start every half second. See Figures 8 and
9 for further details.

The

INSPEC

and

OUTSPEC

pins are used to provide visual feedback to the end user in the following

situations:

1. Datalog Mission Start When a datalog mission is first initiated, the

INSPEC

and

OUTSPEC

pins will

generate four low pulses simultaneously to give the end user a visual indication that a datalog mission
has begun.

2. Request for Status of Data

Following a user request for the status of recorded temperature data, the

INSPEC

pin will generate four

low pulses if the recorded temperature data is within the user defined limits (as set in the Low
Temperature Threshold and High Temperature Threshold registers). If the recorded temperature data
contains any readings that fall outside of these thresholds, the

OUTSPEC

pin will be pulsed four times. If

the request comes after the mission has started (i.e., MIP = 1), but before the first temperature sample has
been recorded, the

INSPEC

and

OUTSPEC

pins will generate a total of four low pulses alternately, starting

with the

OUTSPEC

pin.

The DS1615 provides two methods for the user to request the status of the data. The first method is to
send the Specification Test command over the serial interface. The second method is by holding the

ST

pin low for at least half a second after the datalogger has already been started.

CLOCK, CALENDAR, AND ALARM

The time and calendar information is accessed by reading/ writing the appropriate register bytes. Note
that some bits are set to zero. These bits will always read zero regardless of how they are written. The
contents of the time, calendar, and alarm registers are in the Binary-Coded Decimal (BCD) format.

The DS1615 can run in either 12-hour or 24-hour mode. Bit 6 of the hours register is defined as the 12-
or 24-hour mode select bit. When high, the 12-hour mode is selected. In the 12-hour mode, bit 5 is the
AM/PM bit with logic one being PM. In the 24-hour mode, bit 5 is the second 10-hour bit (20-23 hours).

The DS1615 also contains a time of day alarm. The alarm registers are located in registers 0007h to
000Ah. Bit 7 of each of the alarm registers are mask bits (see Table 2). When all of the mask bits are
logic 0, an alarm will occur once per week when the values stored in time-keeping registers 0000h to
0003h match the values stored in the time of day alarm registers. An alarm will be generated every day
when mask bit of the day alarm register is set to 1. An alarm will be generated every hour when the day
and hour alarm mask bits are set to 1. Similarly, an alarm will be generated every minute when the day,
hour, and minute alarm mask bits are set to 1. When day, hour, minute, and seconds alarm mask bits are
set to 1, an alarm will occur every second.

As a security measure to prevent unauthorized tampering, changing any value in the RTC and Control
registers (with the exception of the Status register) will stop a datalog mission and clear the Mission-in-
Progress (MIP) bit.
