DS4026
10MHz to 51.84MHz TCXO
4 _____________________________________________________________________
TEMPERATURE SENSOR ELECTRICAL CHARACTERISTICS (Note 1)
(V CC = 3.135V to 3.465V, T A = -40°C to +85°C, unless otherwise noted.)
PARAMETER SYMBOL CONDITIONS MIN TYP MAX UNITS
Temperature Sensor Accuracy T -3 +3 °C
Temperature Sensor Conversion
Time
t CONVT 11 ms
Temperature Sensor Resolution N2 12 Bits
AC ELECTRICAL CHARACTERISTICS
(V CC = 3.135V to 3.465V, T A = -40°C to +85°C, unless otherwise noted.) (Note 2)
PARAMETER SYMBOL CONDITIONS MIN TYP MAX UNITS
Standard mode 0 100
SCL Clock Frequency f SCL
Fast mode 100 400
kHz
Standard mode 4.7 Bus Free Time Between STOP
and START Conditions
t BUF
Fast mode 1.3
µs
Standard mode 4.0 Hold Time (Repeated) START
Condition (Note 6)
t HD:STA
Fast mode 0.6
µs
Standard mode 4.7
Low Period of SCL Clock t LOW
Fast mode 1.3
µs
Standard mode 4.0
High Period of SCL Clock t HIGH
Fast mode 0.6
µs
Standard mode 0 0.9 Data Hold Time
(Notes 7, 8)
t HD:DAT
Fast mode 0 0.9
µs
Standard mode 250
Data Setup Time (Note 9) t SU:DAT
Fast mode 100
ns
Standard mode 4.7
Start Setup Time t SU:STA
Fast mode 0.6
µs
Standard mode 20 + 0.1C B 1000 Rise Time of Both SDA and SCL
Signals (Note 10)
t R
Fast mode 20 + 0.1C B 300
ns
Standard mode 20 + 0.1C B 300 Fall Time of Both SDA and SCL
Signals (Note 10)
t F
Fast mode 20 + 0.1C B 300
ns
