MAX5974A/MAX5974B/MAX5974C/MAX5974D
Active-Clamped, Spread-Spectrum,
Current-Mode PWM Controllers
25
Typical Application Circuits (continued)
Chip Information
PROCESS: BiCMOS
Package Information
For the latest package outline information and land patterns,
go to
www.maxim-ic.com/packages . Note that a “+”, “#”, or
“-” in the package code indicates RoHS status only. Package
drawings may show a different suffix character, but the drawing
pertains to the package regardless of RoHS status.
PACKAGE
TYPE
PACKAGE
CODE
OUTLINE
NO.
LAND
PATTERN NO.
16 TQFN-EP T1633+4 21-0136 90-0031
