MAX5974A/MAX5974B/MAX5974C/MAX5974D
Active-Clamped, Spread-Spectrum,
Current-Mode PWM Controllers
20
Typically, f TRI should be set close to 1kHz. The resistor
R DITHER connected from DITHER/SYNC to RT deter-
mines the amount of dither as follows:
RT
DITHER
R 4
%DITHER
3 R
= ×
where %DITHER is the amount of dither expressed as a
percentage of the switching frequency. Setting R
DITHER
to 10 x R RT generates Q10% dither.
Programmable Slope Compensation
The device generates a current ramp at CSSC such that
its peak is 50FA at 80% duty cycle of the oscillator. An
external resistor connected from CSSC to the CS then
converts this current ramp into programmable slope-
compensation amplitude, which is added to the current-
sense signal for stability of the peak current-mode
control loop. The ramp rate of the slope compensation
signal is given by:
CSSC SW
R 50 A f
m
80%
× µ ×
=
where m is the ramp rate of the slope-compensation
signal, R
CSSC is the value of the resistor connected
between CSSC and CS used to program the ramp rate,
and f
SW
is the switching frequency.
Error Amplifier
The MAX5974A/MAX5974B include an internal error
amplifier with a sample-and-hold input. The feedback
input of the MAX5974C/MAX5974D is continuously con-
nected. The noninverting input of the error amplifier is
connected to the internal reference and feedback is
provided at the inverting input. High open-loop gain and
unity-gain bandwidth allow good closed-loop bandwidth
and transient response. Calculate the power-supply out-
put voltage using the following equation:
FB1 FB2
OUT REF
FB2
R R
V V
R
+
= ×
where V REF = 1.52V for the MAX5974A/MAX5974B
and V REF = 1.215V for the MAX5974C/MAX5974D. The
amplifier’s noninverting input is internally connected to
a soft-start circuit that gradually increases the reference
voltage during startup. This forces the output voltage to
come up in an orderly and well-defined manner under all
load conditions.
Applications Information
Startup Time Considerations
The bypass capacitor at IN, C IN , supplies current
immediately after the devices wake up (see the Typical
Application Circuits). Large values of C
IN increase
the startup time, but also supply gate charge for more
cycles during initial startup. If the value of C
IN is too
small, V IN drops below 7V because NDRV does not have
enough time to switch and build up sufficient voltage
across the tertiary output (MAX5974C/MAX5974D) or
coupled inductor output (MAX5974A/MAX5974B), which
powers the device. The device goes back into UVLO
and does not start. Use a low-leakage capacitor for C
IN .
Typically, offline power supplies keep startup times to
less than 500ms even in low-line conditions (85V AC
input for universal offline or 36V DC for telecom applica-
tions). Size the startup resistor, R
IN , to supply both the
maximum startup bias of the device (150FA) and the
charging current for C
IN . C IN must be charged to 20V
within the desired 500ms time period. C IN must store
enough charge to deliver current to the device for at
least the soft-start time (t
SS ) set by C SS . To calculate the
approximate amount of capacitance required, use the
following formula:
G GTOT SW
IN G SS
IN
HYST
I Q f
(I I )(t )
C
V
=
+
=
where I IN is the ICs’ internal supply current (1.8mA)
after startup, Q GTOT is the total gate charge for the
n-channel and p-channel FETs, f SW is the ICs’ switch-
ing frequency, V HYST is the bootstrap UVLO hysteresis
(13V typ), and t SS is the soft-start time. R IN is then cal-
culated as follows:
S(MIN) INUVR
IN
START
V V
R
I
−
≅
where V S(MIN) is the minimum input supply voltage for
the application (36V for telecom), V INUVR is the boot-
strap UVLO wake-up level (20V), and I START is the IN
supply current at startup (150FA max).
Choose a higher value for R
IN than the one calculated
above if a longer startup time can be tolerated in order
to minimize power loss on this resistor.
