MAX5974A/MAX5974B/MAX5974C/MAX5974D
Active-Clamped, Spread-Spectrum,
Current-Mode PWM Controllers
2
Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and functional
operation of the device at these or any other conditions beyond those indicated in the operational sections of the specifications is not implied. Exposure to absolute
maximum rating conditions for extended periods may affect device reliability.
IN to GND ..............................................................-0.3V to +26V
EN, NDRV, AUXDRV to GND .....................-0.3V to (V
IN
+ 0.3V)
RT, DT, FFB, COMP, SS, DCLMP, DITHER/SYNC
to GND .................................................................-0.3V to +6V
FB to GND (MAX5974A/MAX5974B only) ..................-6V to +6V
FB to GND (MAX5974C/MAX5974D only) ..............-0.3V to +6V
CS, CSSC to GND ...................................................-0.8V to +6V
PGND to GND ......................................................-0.3V to +0.3V
Maximum Input/Output Current (continuous)
NDRV, AUXDRV ............................................................100mA
NDRV, AUXDRV (pulsed for less than 100ns) .................. Q1A
Continuous Power Dissipation (T
A
= +70NC) (Note 1)
16-Pin TQFN (derate 20.8mW/NC above +70NC) .......1666mW
Junction-to-Case Thermal Resistance (B
JC
) (Note 1)
16-Pin TQFN ...................................................................7NC/W
Junction-to-Ambient Thermal Resistance (B
JA
) (Note 1)
16-Pin TQFN .................................................................48NC/W
Operating Temperature Range .......................... -40NC to +85NC
Maximum Junction Temperature .....................................+150NC
Storage Temperature Range ............................ -65NC to +150NC
Lead Temperature (soldering, 10s) ................................+300NC
Soldering Temperature (reflow) ......................................+260NC
ELECTRICAL CHARACTERISTICS
(V
IN
= 12V (for MAX5974A/MAX5974C, bring V
IN
up to 21V for startup), V
CS
= V
CSSC
= V
DITHER/SYNC
= V
FB
= V
FFB
= V
DCLMP
=
V
GND
, V
EN
= +2V, NDRV = AUXDRV = SS = COMP = unconnected, R
RT
= 34.8kI, R
DT
= 25kI, C
IN
= 1FF, T
A
= -40NC to +85NC,
unless otherwise noted. Typical values are at T
A
= +25NC.) (Note 2)
ABSOLUTE MAXIMUM RATINGS
Note 1: Package thermal resistances were obtained using the method described in JEDEC specification JESD51-7, using a four-
layer board. For detailed information on package thermal considerations, refer to
www.maxim-ic.com/thermal-tutorial
.
PARAMETER
SYMBOL
CONDITIONS
MIN
TYP
MAX
UNITS
UNDERVOLTAGE LOCKOUT/STARTUP (IN)
Bootstrap UVLO Wakeup Level
V
INUVR
V
IN
rising
MAX5974A/
MAX5974C
19.1
19.8
20.4
V
MAX5974B/
MAX5974D
9.4
9.8
10.25
Bootstrap UVLO Shutdown
Level
V
INUVF
V
IN
falling
6.65
7
7.35
V
IN Supply Current in
Undervoltage Lockout
I
START
V
IN
= +18V (for MAX5974A/
MAX5974C);
V
IN
= +9V (for MAX5974B/MAX5974D),
when in bootstrap UVLO
100
150
F
A
IN Supply Current After Startup
I
C
V
IN
= +12V
1.8
3
mA
ENABLE (EN)
Enable Threshold
V
ENR
V
EN
rising
1.17
1.215
1.26
V
V
ENF
V
EN
falling
1.09
1.14
1.19
Input Current
I
EN
1
F
A
OSCILLATOR (RT)
RT Bias Voltage
V
RT
1.23
V
NDRV Switching Frequency
Range
f
SW
100
600
kHz
NDRV Switching Frequency
Accuracy
-8
+8
%
Maximum Duty Cycle
D
MAX
f
SW
= 250kHz
79
80
82
%
