Table 6. Peripheral Register Bit Reset Values
REGISTER BIT
REGISTER
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
PO0 1 1 1 1 1 1 1 1
PO1 1 1 1 1 1 1 1 1
PO2 1 1 1 1 1 1 1 1
PO3 1 1 1 1 1 1 1 1
EIF0 0 0 0 0 0 0 0 0
EIE0 0 0 0 0 0 0 0 0
PI0 s s s s s s s s
PI1 s s s s s s s s
PI2 s s s s s s s s
PI3 s s s s s s s s
EIES0 0 0 0 0 0 0 0 0
PD0 0 0 0 0 0 0 0 0
PD1 0 0 0 0 0 0 0 0
PD2 0 0 0 0 0 0 0 0
PD3 0 0 0 0 0 0 0 0
RTRM 0 0 s s s s s s
RCNT 0 0 0 0 0 0 0 0 0 0 0 0 1 0 0 s
RTSS s s s s s s s s
RTSH s s s s s s s s s s s s s s s s
RTSL s s s s s s s s s s s s s s s s
RSSA 0 0 0 0 0 s s s s s s s s s s s
RASH 0 0 0 0 s s s s
RASL s s s s s s s s s s s s s s s s
T0CN 0 0 0 0 0 0 0 0
T0L 0 0 0 0 0 0 0 0
T0H 0 0 0 0 0 0 0 0
SCON0 0 0 0 0 0 0 0 0
SBUF0 0 0 0 0 0 0 0 0
SCON1 0 0 0 0 0 0 0 0
SBUF1 0 0 0 0 0 0 0 0
SMD0 0 0 0 0 0 0 0 0
PR0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
SMD1 0 0 0 0 0 0 0 0
PR1 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
ICDF 0 0 0 0 0 0 0 0
T1CN 0 0 0 0 0 0 0 0
T1L 0 0 0 0 0 0 0 0
