MAXQ3120
High-Precision ADC
Mixed-Signal Microcontroller
____________________________________________________________________ 17
Table 5. Peripheral Register Bit Functions
REGISTER BIT
REGISTER
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
PO0 PO0 (8 bits)
PO1 PO1 (8 bits)
PO2 PO2 (8 bits)
PO3 PO3 (8 bits)
EIF0 — — — — — IE2 IE1 IE0
EIE0 — — — — — EX2 EX1 EX0
PI0 PI0 (8 bits)
PI1 PI1 (8 bits)
PI2 PI2 (8 bits)
PI3 PI3 (8 bits)
EIES0 — — — — — IT2 IT1 IT0
PD0 PD0 (8 bits)
PD1 PD1 (8 bits)
PD2 PD2 (8 bits)
PD3 PD3 (8 bits)
RTRM — — TSGN TRM (5 bits)
RCNT WE — — — — — FT SQE ALSF ALDF RDYE RDY BUSY ASE ADE RTCE
RTSH RTSH (16 bits)
RTSL RTSL (16 bits)
RSSA — — — — — RSSA (11 bits)
RASH — — — — RASH (4 bits)
RASL RASL (16 bits)
T0CN ET0 T0M TF0 TR0 GATE C/T M1 M0
T0L T0L (8 bits)
T0H T0H (8 bits)
SCON0 SM0/FE SM1 SM2 REN TB8 RB8 TI RI
SBUF0 SBUF0 (8 bits)
SCON1 SM0/FE SM1 SM2 REN TB8 RB8 TI RI
SBUF1 SBUF1 (8 bits)
SMD0 EPWM OFS — — — ESI SMOD FEDE
PR0 PR0 (16 bits)
SMD1 — — — — — ESI SMOD FEDE
PR1 PR1 (16 bits)
