MAXQ3120
High-Precision ADC
Mixed-Signal Microcontroller
____________________________________________________________________ 13
Table 1. System Register Map
REGISTER
INDEX
AP
(8h)
A
(9h)
PFX
(Bh)
IP
(Ch)
SP
(Dh)
DPC
(Eh)
DP
(Fh)
0xh AP A[0] PFX IP — — —
1xh APC A[1] — — SP — —
2xh — A[2] — — IV — —
3xh — A[3] — — — Offs DP[0]
4xh PSF A[4] — — — DPC —
5xh IC A[5] — — — GR —
6xh IMR A[6] — — LC[0] GRL —
7xh — A[7] — — LC[1] BP DP[1]
8xh SC A[8] — — — GRS —
9xh — A[9] — — — GRH —
Axh — A[10] — — — GRXL —
Bxh IIR A[11] — — — BP[offs] —
Cxh — A[12] — — — — —
Dxh — A[13] — — — — —
Exh CKCN A[14] — — — — —
Fxh WDCN A[15] — — — — —
Note: Names that appear in italics indicate that all bits of a register are read-only. Names that appear in bold indicate that a register
is 16 bits wide. Registers in module AP are bit addressable.
