MAXQ3120
High-Precision ADC
Mixed-Signal Microcontroller
16 ____________________________________________________________________
Table 4. Peripheral Register Map
REGISTER
INDEX
M0
(0h)
M1
(1h)
M2
(2h)
M3
(3h)
M4
(4h)
M5
(5h)
00h PO0 T0CN T1CN MCNT — —
01h PO1 T0L T1L MA — —
02h PO2 T0H T1H MB — —
03h PO3 SCON0 T2CNA MC2 — —
04h — SBUF0 T2H MC1 — —
05h — SCON1 T2RH MC0 — —
06h EIF0 SBUF1 T2CH MC1R — —
07h EIE0 — IRCN MC0R — —
08h PI0 — T1CL ADCN — —
09h PI1 SMD0 T1CH PHC — —
0Ah PI2 PR0 T1MD AD0 — —
0Bh PI3 SMD1 T2CNB AD1 — —
0Ch EIES0 PR1 T2V ATRM — —
0Dh — — T2R LCRA — —
0Eh — — T2C LCFG — —
0Fh — — T2CFG — — —
10h PD0 — — LCD0 — —
11h PD1 — — LCD1 — —
12h PD2 — — LCD2 — —
13h PD3 — — LCD3 — —
14h — — — LCD4 — —
15h — — — LCD5 — —
16h — — — LCD6 — —
17h — — — LCD7 — —
18h RTRM — — LCD8 — —
19h RCNT — — LCD9 — —
1Ah RTSS — — LCD10 — —
1Bh RTSH ICDF — LCD11 — —
1Ch RTSL — — LCD12 — —
1Dh RSSA — — LCD13 — —
1Eh RASH — — — — —
1Fh RASL — — — — —
Note: Names that appear in italics indicate that all bits of a register are read-only. Names that appear in bold indicate that a register
is 16 bits wide. Registers in module AP are bit addressable.
