Page 6
6
TH7841A
1998A–IMAGE–05/02
Notes:
1. Value measured with respect to zero reference level (see Figure 1).
2. Conversion factor is typically 1.1 µV/e-.
3.
∆R/R is defined as
where RA is responsivity of video output A
RB is responsivity of video output B
4. Measured in Correlated Double Sampling (C.D.S.) mode.
Figure 2. Typical Spectral Response
Table 5. Electro-optical Performance
Parameter
Symbol
Values
Unit
Note
Min
Typ
Max
Saturation Output Voltage
V
SAT
1.3
1.8
2.2
V
Saturation Exposure
E
SAT
0.33
µJ/cm
2
Responsivity
R
2.5
2.9
V/µJ/cm
2
Responsivity Unbalance
∆R/R
2
8
%
Photo-response No-uniformity Peak-to-
peak
PRNU
±5
±10
% V
OS
V
OS
= 50 mV to 1V
Contrast Transfer Function at FN
(38 I p/mm)
CTF
70
%
V
OS
= 0.75V
Temporal Noise in Darkness
160
µVrms
Dynamic Range (Relative to rms Noise)
DR
3000
6000
Average Dark Signal
V
DS
0.08
0.5
mV
Dark Signal Non-uniformity
DSNU
0.15
0.5
mV
200 RA
RB
–
RA
R B
+
----------------------------------
