3
TH7841A
1998A–IMAGE–05/02
Operating Conditions (T = 25°C)
Notes: 1. It is recommended to maintain V
DR
at V
DD
- 2V.
2. V
T
nominal =
3. No use for operation – For testing purpose only.
Basic Internal
Configuration
Note: 1. Make the straps as short as possible to avoid any parasitic coupling to these connec-
tions. The load capacitance introduced by the strap should not exceed 5 pF.
Table 1. DC Characteristics
Parameter Symbol
Values
Unit Note Min Typ Max
Output Amplifier Drain Supply V
DD
14 15 16 V
Reset DC Bias V
DR
12 13 14.5 V (1)
Output Gate DC Bias V
GS
5.5 6 6.5 V
Photosensitive Zone and
Register DC Bias
V
T
6 6.5 7 V (2)
Substrate Bias V
SS
0.0 0.0
Test Point 1 TP1 V
DD
V (3)
Test Points 2 and 3 TP2, TP3 V
SS
V (3)
V
Φ
T
( )high
V
Φ
T
( )low
+
2
------------------------------------------------------------ 5%
±
S Φ
ECHA
and Φ
RA
internal to TH7841A
S Φ
ECHB
and Φ
RB
Table 2. Selection of Nominal Mode
Option Implementation Note
Internal Sampling
V
INH
(16) Connected to V
SS
S
Φ
ECHA
(4) and
Φ
ECHA
(3) Strapped
S Φ
ECHB
(24) and Φ
ECHB
(25) Strapped
(1)
Internal Reset Φ
RA
(5) and Φ
RB
(21) Connected to VDD
