MAX9768
10W Mono Class D Speaker
Amplifier with Volume Control
______________________________________________________________________________________ 19
Table 6. Speaker Volume Levels (continued)
V5 V4 V3 V2 V1 V0
VOLUME
POSITION
VOLUME
LEVEL (dB)
STEP SIZE
(dB)
0 1 1 1 1 1 31 -17.5 2.2
0 1 1 1 1 0 30 -19.7 1.9
0 1 1 1 0 1 29 -21.6 1.9
0 1 1 1 0 0 28 -23.5 1.7
0 1 1 0 1 1 27 -25.2 2.0
0 1 1 0 1 0 26 -27.2 2.6
0 1 1 0 0 1 25 -29.8 1.6
0 1 1 0 0 0 24 -31.5 2.0
0 1 0 1 1 1 23 -33.4 2.5
0 1 0 1 1 0 22 -36.0 1.6
0 1 0 1 0 1 21 -37.6 2.0
0 1 0 1 0 0 20 -39.6 2.5
0 1 0 0 1 1 19 -42.1 1.6
0 1 0 0 1 0 18 -43.7 2.0
0 1 0 0 0 1 17 -45.6 2.5
0 1 0 0 0 0 16 -48.1 2.5
0 0 1 1 1 1 15 -50.6 3.5
0 0 1 1 1 0 14 -54.2 2.5
0 0 1 1 0 1 13 -56.7 3.5
0 0 1 1 0 0 12 -60.2 2.5
0 0 1 0 1 1 11 -62.7 3.5
0 0 1 0 1 0 10 -66.2 2.5
0 0 1 0 0 1 9 -68.7 3.5
0 0 1 0 0 0 8 -72.2 2.5
0 0 0 1 1 1 7 -74.7 3.5
0 0 0 1 1 0 6 -78.3 2.5
0 0 0 1 0 1 5 -80.8 3.5
0 0 0 1 0 0 4 -84.3 2.5
0 0 0 0 1 1 3 -86.8 3.5
0 0 0 0 1 0 2 -90.3 2.5
0 0 0 0 0 1 1 -92.8 —
0 0 0 0 0 0 0 (MUTE) -161.5 —
