MAX6791–MAX6796
High-Voltage, Micropower, Single/Dual Linear
Regulators with Supervisory Functions
_______________________________________________________________________________________
9
Typical Operating Characteristics (continued)
(V
IN
= V
EN
= 14V, C
IN
= 0.1µF, C
OUT
= 10µF, T
J
= T
A
= +25°C, unless otherwise noted.)
10,000
1000
100
10
1
0.1
0.0001
0.01
0.1
0.001
1
RESET TIMEOUT PERIOD
vs. C
CSRT
MAX6791-96toc16
C
CSRT
(
µF)
RESET TIMEOUT PERIOD (ms)
WATCHDOG TIMEOUT PERIOD
vs. C
CSWT
MAX6791-96toc17
C
CSWT
(
µF)
WATCHDOG TIMEOUT PERIOD
0.01
0.001
10
100
1000
10,000
100,000
1
0.0001
0.1
LOAD-TRANSIENT RESPONSE
MAX6791-96toc18
OUT1
I
OUT1
100mA/div
1mA
1V/div
400
µs/div
MAX6796
C
OUT
= 10
µF
V
OUT
= 5V
V
IN
= 14V
V
OUT
AC-
COUPLED
LOAD-TRANSIENT RESPONSE
MAX6791-96toc19
I
OUT
OUT
100mA/div
1mA
500mV/div
400
µs/div
OUT AC-
COUPLED
MAX6796
V
IN
= 14V
V
OUT
= 5V
LINE-TRANSIENT RESPONSE
MAX6791-96toc20
V
IN
OUT
10V/div
(AC-COUPLED)
20mV/div
1ms/div
OUT AC-
COUPLED
MAX6796
I
LOAD
= 10mA
