MAX6791–MAX6796
High-Voltage, Micropower, Single/Dual Linear
Regulators with Supervisory Functions
_______________________________________________________________________________________
3
ELECTRICAL CHARACTERISTICS (continued)
(V
IN
= 14V, C
IN
= 1µF, C
OUT
= 10µF, T
A
= T
J
= -40°C to +125°C, unless otherwise noted. Typical values are at T
A
= T
J
= +25°C.)
(Note 1)
PARAMETER
SYMBOL
CONDITIONS
MIN
TYP
MAX
UNITS
L/M, I
LOAD
= I
LOAD1
= 1mA
4.858
4.974
5.090
L/M, I
LOAD
= 150mA (MAX6791–MAX6794),
V
IN
= 8V
4.811
4.945
5.078
L/M, I
LOAD
= 300mA (MAX6795/MAX6796),
V
IN
= 8V
4.850
5
5.150
T/S, I
LOAD
= I
LOAD1
= 1mA
3.206
3.282
3.360
T/S, I
LOAD
= 150mA (MAX6791–MAX6794),
V
IN
= 6V
3.175
3.263
3.351
T/S, I
LOAD
= 300mA (MAX6795/MAX6796),
V
IN
= 6V
3.201
3.3
3.399
Z/Y, I
LOAD
= I
LOAD1
= 1mA
2.429
2.487
2.546
Z/Y, I
LOAD
= 150mA (MAX6791–MAX6794),
V
IN
= 5.5V
2.405
2.472
2.539
Z/Y, I
LOAD
= 300mA (MAX6795/MAX6796),
V
IN
= 5.5V
2.425
2.5
2.575
W/V, I
LOAD
= I
LOAD1
= 1mA
1.748
1.791
1.832
W/V, I
LOAD
= 150mA (MAX6791–MAX6794),
V
IN
= 5V
1.731
1.780
1.828
Output Voltage
V
OUT
/
V
OUT1
W/V, I
LOAD
= 300mA (MAX6795/MAX6796),
V
IN
= 5V
1.746
1.8
1.854
V
I
LOAD2
= 1mA
4.858
4.974
5.090
Output Voltage
(MAX6791–MAX6794)
V
OUT2
I
LOAD2
= 150mA
4.811
4.945
5.079
V
SET/SET1 Threshold Voltage
V
SET
I
LOAD
= I
LOAD1
= 1mA, OUT/OUT1 = 5V
1.207
1.2315
1.256
V
Adjustable Output Voltage
V
OUT
1.8
11.0
V
SET/SET1 rising
124
Dual-Mode™ SET Threshold
SET/SET1 falling
62
mV
SET/SET1 Input Current
SET/SET1 = 1V, V
IN
= 11V
-100
+100
nA
L/M, I
LOAD
= 20mA (Note 2)
84
130
L/M, I
LOAD
= 300mA (Note 2)
1200
1800
(MAX6795/
MAX6796)
T/S, I
LOAD
= 300mA (Note 3)
1700
2400
L/M, I
LOAD
= 150mA (Note 2)
1000
1800
L/M, I
LOAD
= 10mA (Note 2)
84
130
Dropout Voltage
∆V
DO
(MAX6791–
MAX6794)
T/S, I
LOAD
= 150mA (Note 3)
1700
2400
mV
M AX6795/M AX6796, i nfer red fr om d r opout test
300
Guaranteed Output Current
(Note 4)
MAX6791–MAX 6794, inferr ed from d rop out test
150
mA
Dual Mode is a trademark of Maxim Integrated Products, Inc.
