Functional diagrams (continued) – Rainbow Electronics MAX6796 User Manual
Page 15
MAX6791–MAX6796
High-Voltage, Micropower, Single/Dual Linear
Regulators with Supervisory Functions
______________________________________________________________________________________
15
Functional Diagrams (continued)
MAX6795/MAX6796
THERMAL
PROTECTION
CONTROL
LOGIC
1.23V
124mV
OUT
SET
RESET
CSRT
WDI
CSWT
WD-DIS
PFO
GND
PFI
1.138V
OR
1.076V
OVERCURRENT
PROTECTION
RESET
TIMEOUT
RESET
IN
GATEP
ENABLE
HOLD
WATCHDOG
TIMEOUT
