MAX4028/MAX4029
Triple/Quad, 2:1 Video
Multiplexer-Amplifiers with Input Clamps
4 _______________________________________________________________________________________
Typical Operating Characteristics
(V
CC
= +5V, GND = 0V, V DISABLE = +5V, R
L
= 150 Ω to GND, C
IN
= 0.1µF, R
KEYREF
= 6.04k Ω ±1%, T
A
= +25°C, unless otherwise
noted.)
SMALL-SIGNAL BANDWIDTH
vs. FREQUENCY
MAX4028 toc01
FREQUENCY (Hz)
SMALL-SIGNAL BANDWIDTH (dB)
100M 10M 1M
-1
0
1
2
3
4
5
6
7
8
-2
100k 1G
V OUT = 100mV P-P
SMALL-SIGNAL GAIN FLATNESS
vs. FREQUENCY
MAX4028 toc02
FREQUENCY (Hz)
GAIN FLATNESS (dB)
100M 10M 1M
5.3
5.4
5.5
5.6
5.7
5.8
5.9
6.0
6.1
6.2
5.2
100k 1G
V OUT = 100mV P-P
LARGE-SIGNAL BANDWIDTH
vs. FREQUENCY
MAX4028 toc03
FREQUENCY (Hz)
LARGE-SIGNAL BANDWIDTH (dB)
100M 10M 1M
-1
0
1
2
3
4
5
6
7
8
-2
100k 1G
V OUT = 2V P-P
LARGE-SIGNAL GAIN FLATNESS
vs. FREQUENCY
MAX4028 toc04
FREQUENCY (Hz)
LARGE-SIGNAL GAIN FLATNESS (dB)
100M 10M 1M
5.3
5.4
5.5
5.6
5.7
5.8
5.9
6.0
6.1
6.2
5.2
100k 1G
V OUT = 2V P-P
DIFFERENTIAL GAIN AND PHASE
MAX4028 toc05
DIFFERENTIAL GAIN (%)
6th 5th 4th 3rd 2nd
-0.1
-0.2
-0.3
0
0.1
0.2
0.3
1st
DIFFERENTIAL PHASE (deg) 6th 5th 4th 3rd 2nd
-0.02
-0.04
-0.06
0
0.02
0.04
0.06
1st
POWER-SUPPLY REJECTION RATIO
vs. FREQUENCY
MAX4028 toc06
FREQUENCY (Hz)
PSRR (dB)
100M 10M 1M 100k 10k
-60
-50
-40
-30
-20
-10
0
-70
1k 1G
OFF-ISOLATION
vs. FREQUENCY
MAX4028 toc07
FREQUENCY (Hz)
OFF-ISOLATION (dB)
100M 10M 1M
-120
-100
-80
-60
-40
-20
0
-140
100k 1G
ALL-HOSTILE CROSSTALK (CHANNEL TO
CHANNEL) vs. FREQUENCY
MAX4028 toc08
FREQUENCY (Hz)
CROSSTALK (dB)
100M 10M 100k 1M
-70
-60
-50
-40
-30
-20
-10
0
-80
10k 1G
ALL-HOSTILE CROSSTALK (A TO B ON ANY
CHANNEL) vs. FREQUENCY
MAX4028 toc09
FREQUENCY (Hz)
CROSSTALK (dB)
100M 10M 1M
-90
-80
-70
-60
-50
-40
-30
-20
-10
0
-100
100k 1G
