MAX4028/MAX4029
Triple/Quad, 2:1 Video
Multiplexer-Amplifiers with Input Clamps
2
_______________________________________________________________________________________
ABSOLUTE MAXIMUM RATINGS
DC ELECTRICAL CHARACTERISTICS
(V
CC
= +5V, GND = 0V, R
L
= 150
Ω to GND, V
DISABLE
= +5V, R
KEYREF
= 6k
Ω, C
IN
= 0.1µF to GND, T
A
= T
MIN
to T
MAX
, unless otherwise
noted. Typical values are at T
A
= +25°C.) (Note 2)
Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and functional
operation of the device at these or any other conditions beyond those indicated in the operational sections of the specifications is not implied. Exposure to
absolute maximum rating conditions for extended periods may affect device reliability.
Supply Voltage (V
CC
to GND) ..................................-0.3V to +6V
IN_A, IN_B, OUT_.......................................-0.3V to (V
CC
+ 0.3V)
DISABLE, A/B, KEYREF, CLAMP/KEY_......-0.3V to (V
CC
+ 0.3V)
Current Into IN_A, IN_B ...................................................±0.5mA
Short-Circuit Duration (V
OUT
to GND)........................Continuous
Short-Circuit Duration (V
OUT
to V
CC
) .............................(Note 1)
Continuous Power Dissipation (T
A
= +70°C)
16-Pin TSSOP (derate 9.4mW/°C above +70°C) .........755mW
16-Pin Wide SO (derate 9.5mW/°C above +70°C) ......762mW
20-Pin TSSOP (derate 11mW/°C above +70°C) ..........879mW
20-Pin Wide SO (derate 10mW/°C above +70°C) .......800mW
Operating Temperature Range ...........................-40°C to +85°C
Junction Temperature ......................................................+150°C
Storage Temperature Range .............................-65°C to +150°C
Lead Temperature (soldering, 10s) .................................+300°C
PARAMETER
SYMBOL
CONDITIONS
MIN
TYP
MAX
UNITS
Operating Supply Voltage Range
V
CC
Guaranteed by PSRR
4.5
5.5
V
MAX4028, R
L
=
∞
29
40
Quiescent Supply Current
I
CC
MAX4029, R
L
=
∞
38
55
mA
MAX4028
9
15
Disable Supply Current
V
DISABLE
= 0V
MAX4029
11
20
mA
Clamp (Note 3)
0.32
0.4
0.48
Output Clamp Voltage
V
CLAMP
Key clamp (Note 4)
1.1
V
Input Clamping Current
I
IN
Input voltage = input clamp + 0.5V
5
18
µA
Clamp Voltage Matching
∆V
CLAMP
Measured at output
10
mV
Clamp Voltage Drift
TC
VCLAMP
Measured at output
80
µV/°C
Input Resistance
R
IN
7
M
Ω
Output Resistance
R
OUT
0.7
Ω
Disable Output Resistance
R
OUT
V
DISABLE
= 0V
2
k
Ω
Power-Supply Rejection Ratio
PSRR
4.5V < V
CC
< 5.5V (Note 5)
48
58
dB
Voltage Gain
A
VCL
1.9
2.0
2.1
V/V
Channel-to-Channel Gain Matching
∆A
VCL
±1
±2
%
Output-Voltage High
V
OH
V
CLAMP
+ 2.4
V
Output-Voltage Low
V
OL
V
CLAMP
V
Output Current
I
OUT
30
mA
LOGIC INPUT CHARACTERISTICS (
DISABLE , A/B, CLAMP/KEY_)
Logic-Low Threshold
V
IL
0.8
V
Logic-High Threshold
V
IH
2.0
V
Logic-Low Input Current
I
IL
V
IL
= 0V
6.6
25
µA
Logic-High Input Current
I
IH
V
IH
= V
CC
1.2
25
µA
Note 1: Do not short V
OUT
to V
CC
.
