MAX4028/MAX4029
Triple/Quad, 2:1 Video
Multiplexer-Amplifiers with Input Clamps
_______________________________________________________________________________________
3
AC ELECTRICAL CHARACTERISTICS
(V
CC
= +5V, GND = 0V, R
L
= 150
Ω to GND, V
DISABLE
= +5V, R
KEYREF
= 6k
Ω, C
IN
= 0.1µF, T
A
= T
MIN
to T
MAX
, unless otherwise noted.
Typical values are at T
A
= +25°C.)
Note 2: All devices are 100% production tested at T
A
= +25°C. Specifications over temperature are guaranteed by design.
Note 3: The clamp voltage at the input is V
CLAMP
(measured at the output) divided by gain + V
BE
.
Note 4: The key-clamp voltage is above the sync-tip clamp voltage by approximately 0.7V, and is adjusted by varying R
KEYREF
.
Note 5: Measured at f = 100Hz at thermal equilibrium.
PARAMETER
SYMBOL
CONDITIONS
MIN
TYP
MAX
UNITS
Small-Signal -3dB Bandwidth
BW
SS
V
OUT
= 100mV
P-P
210
MHz
Large-Signal -3dB Bandwidth
BW
LS
V
OUT
= 2V
P-P
130
MHz
Small-Signal 0.1dB Gain Flatness
Bandwidth
BW
0.1dBSS
V
OUT
= 100mV
P-P
30
MHz
Large-Signal 0.1dB Gain Flatness
Bandwidth
BW
0.1dBLS
V
OUT
= 2V
P-P
30
MHz
Slew Rate
SR
V
OUT
= 2V
P-P
300
V/µs
Settling Time to 0.1%
t
S
V
OUT
= 2V step
20
ns
Power-Supply Rejection Ratio
PSRR
f = 100kHz
55
dB
Output Impedance
Z
O
f = 100kHz
0.7
Ω
Differential Gain Error
DG
5-step modulated staircase
0.2
%
Differential Phase Error
DP
5-step modulated staircase
0.4
degrees
Group Delay
D/dT
f = 3.58MHz or 4.43MHz
1.0
ns
Peak Signal to RMS Noise
SNR
100kHz to 30MHz
70
dB
Channel-to-Channel Crosstalk
X
TALK
f = 100kHz
73
dB
A/B Crosstalk
X
TALKAB
f = 100kHz
91
dB
Off-Isolation
A
ISO
V
OUT_
= 2V
P-P
, f = 100kHz
108
dB
Droop
D
R
Guaranteed by input clamp current
2
%
SWITCHING CHARACTERISTICS
Channel Switching Time
t
SW
20
ns
Enable Time
t
ON
0.1
µs
Disable Time
t
OFF
0.1
µs
Switching Transient
±10
mV
P-P
