MAX13046E/MAX13047E
Single- and Dual-Bidirectional
Low-Level Translator
_______________________________________________________________________________________
7
Typical Operating Characteristics (continued)
(V
CC
= +3.3V, V
L
= +1.8V, R
L
= 1MΩ, C
L
= 15pF, push-pull driving data rate = 8Mbps, T
A
= +25°C, unless otherwise noted.)
PROPAGATION DELAY vs. CAPACITIVE LOAD
(PUSH-PULL DRIVING ONE I/O V
L
)
CAPACITIVE LOAD (pF)
PROPAGATION DELAY (ns)
MAX13046E/7E toc10
0
10
20
30
40
50
0
1
2
3
4
5
6
7
RISE/FALL TIME vs. CAPACITIVE LOAD
(PUSH-PULL DRIVING ONE I/O V
CC
)
CAPACITIVE LOAD (pF)
RISE/FALL TIME (ns)
MAX13046E/7E toc11
0
10
20
30
40
50
0
2
4
6
8
10
12
t
RVL
t
FVL
PROPAGATION DELAY vs. CAPACITIVE LOAD
(PUSH-PULL DRIVING ONE I/O V
CC
)
CAPACITIVE LOAD (pF)
PROPAGATION DELAY (ns)
MAX13046E/7E toc12
0
10
20
30
40
50
0
0.5
1.0
1.5
2.0
2.5
3.0
3.5
RAIL-TO-RAIL DRIVING
(DRIVING ONE I/O V
L
)
MAX13046E/7E toc13
25ns/div
I/O V
L
I/O V
CC
1V/div
1V/div
EXISTING SHUTDOWN MODE
MAX13046E/7E toc14
250ns/div
I/O V
L
I/O V
CC
1V/div
2V/div
1V/div
SHDN
