MAX13046E/MAX13047E
Single- and Dual-Bidirectional
Low-Level Translator
4 _______________________________________________________________________________________
TIMING CHARACTERISTICS FOR +1.2V ≤ V L ≤ MINIMUM OF EITHER +3.6V OR (V CC + 0.3V)
(V CC ≤ ±5.5V, +1.2V ≤ V L ≤ minimum of either +3.6V or ((V CC + 0.3V)), R S = 50Ω, R L = 1MΩ, CL = 15pF, T A = -40°C to +85°C, unless
otherwise noted. Typical values are V CC = +3.3V, V L = +1.8V at T A = +25°C.) (Notes 2, 3, 5)
PARAMETER SYMBOL CONDITIONS MIN TYP MAX UNITS
Push-pull driving, Figure 1a 7 25
I/O V CC Rise Time t RVCC
Open-drain driving, Figure 1c 170 400
ns
Push-pull driving, Figure 1a 6 37
I/O V CC Fall Time t FVCC
Open-drain driving, Figure 1c 20 50
ns
Push-pull driving, Figure 1b 8 30
I/O V L Rise Time t RVL
Open-drain driving, Figure 1d 180 400
ns
Push-pull driving, Figure 1 3 56
I/O V L Fall Time t FVL
Open-drain driving, Figure 1d 30 60
ns
Push-pull driving 5 30
t PD-VL-VCC Driving I/O V L
Open-drain driving 210 1000
Push-pull driving 4 30
Propagation Delay
t PD-VCC-VL Driving I/O V CC
Open-drain driving 190 1000
ns
Push-pull driving 20
Channel-to-Channel Skew t SKEW
Each translator
equally loaded
Open-drain driving 50
ns
Push-pull driving 8 Mbps
Maximum Data Rate
Open-drain driving 500 kbps
TIMING CHARACTERISTICS FOR +1.1V ≤ V L ≤ +1.2V
(V CC ≤ ±5.5V, +1.1V ≤ V L ≤ +1.2V, R S = 50Ω, R L = 1MΩ, C L = 15pF, T A = -40°C to +85°C, unless otherwise noted. Typical values are
V CC = +3.3V, V L = +1.8V at T A = +25°C.) (Notes 2, 3, 5)
PARAMETER SYMBOL CONDITIONS MIN TYP MAX UNITS
Push-pull driving, Figure 1a 7 200
I/O V CC Rise Time t RVCC
Open-drain driving, Figure 1c 170 400
ns
Push-pull driving, Figure 1a 6 37
I/O V CC Fall Time t FVCC
Open-drain driving, Figure 1c 20 50
ns
Push-pull driving, Figure 1b 8 30
I/O V
L
Rise Time t
RVL
Open-drain driving, Figure 1d 180 400
ns
Push-pull driving, Figure 1 3 30
I/O V L Fall Time t FVL
Open-drain driving, Figure 1d 30 60
ns
Push-pull driving 5 200
t PD-VL-VCC Driving I/O V L
Open-drain driving 210 1000
Push-pull driving 4 200
Propagation Delay
t PD-VCC-VL Driving I/O V CC
Open-drain driving 190 1000
ns
Push-pull driving 20
Channel-to-Channel Skew t
SKEW
Each translator
equally loaded
Open-drain driving 50
ns
Push-pull driving 1.2 Mbps
Maximum Data Rate
Open-drain driving 500 kbps
