Rainbow Electronics MAX9512 - Manual (Page 6)

MAX9512
Video Filter Amplifier with SmartSleep
and Y/C Mixer Circuit
6 _ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ _
Typical Operating Characteristics
(V DD = SHDN = +3.3V, V SMARTSLEEP = GND = 0V. Video outputs have R L = 150Ω connected to GND. T A = +25°C, unless otherwise
noted.)
SMALL-SIGNAL GAIN
vs. FREQUENCY
MAX9512 toc01
FREQUENCY (Hz)
OUTPUT AMPLITUDE (dB)
10M 1M
-50
-40
-30
-20
-10
0
10
20
-60
100k 100M
V OUT = 100mV P-P
NORMALIZED TO 1MHz
SMALL-SIGNAL GAIN FLATNESS
vs. FREQUENCY
MAX9512 toc02
FREQUENCY (Hz)
OUTPUT AMPLITUDE (dB)
1M 10M
-0.8
-0.6
-0.4
-0.2
0
0.2
0.4
0.6
0.8
1.0
-1.0
100k 100M
V OUT = 100mV P-P
NORMALIZED TO 1MHz
LARGE-SIGNAL GAIN
vs. FREQUENCY
MAX9512 toc03
FREQUENCY (Hz)
OUTPUT AMPLITUDE (dB)
10M 1M
-50
-40
-30
-20
-10
0
10
20
-60
100k 100M
V OUT = 2V P-P
NORMALIZED TO 1MHz
LARGE-SIGNAL GAIN FLATNESS
vs. FREQUENCY
MAX9512 toc04
FREQUENCY (Hz)
OUTPUT AMPLITUDE (dB)
1M 10M
-0.8
-0.6
-0.4
-0.2
0
0.2
0.4
0.6
0.8
1.0
-1.0
100k 100M
V OUT = 2V P-P
NORMALIZED TO 1MHz
GROUP DELAY
MAX9512 toc05
FREQUENCY (Hz)
DELAY (ns)
10M 1M
0
25
50
75
100
125
150
-25
100k 100M
V OUT = 2V P-P
POWER-SUPPLY REJECTION RATIO
vs. FREQUENCY
MAX9512 toc06
FREQUENCY (Hz)
PSRR (dB)
10M 1M 100k
-70
-60
-50
-40
-30
-20
-10
0
-80
10k 100M
QUIESCENT SUPPLY CURRENT
vs. TEMPERATURE
MAX9512 toc07
TEMPERATURE ( °C)
SUPPLY CURRENT (mA)
100 75 50 25 0 -25
11.5
12.0
12.5
13.0
13.5
14.0
11.0
-50 125
VOLTAGE GAIN
vs. TEMPERATURE
MAX9512 toc08
TEMPERATURE ( °C)
VOLTAGE GAIN (V/V)
100 75 50 25 0 -25
1.96
1.97
1.98
2.00
1.99
2.01
2.02
1.95
-50 125
