AC CHARACTERISTICS (continued)
(V DD = V SHDN = +3.3V, V SMARTSLEEP = GND = 0V, R L = 150Ω to GND. T A = T MIN to T MAX , unless otherwise noted. Typical values
are at T A = +25°C.) (Note 1)
PARAMETER SYMBOL CONDITIONS MIN TYP MAX UNITS
2T Bar Response
Bar time is 18µs, the beginning 2.5% and
the ending 2.5% of the bar time is ignored,
2T = 200ns or 250ns
0.2 K%
2T Pulse-to-Bar K Rating
Bar time is 18µs, the beginning 2.5% and
the ending 2.5% of the bar time is ignored,
2T = 200ns or 250ns
0.3 K%
Nonlinearity 5-step staircase 0.1 %
Interchannel Timing Error
Difference in time between the 50% point of
the output signals, YOUT to COUT
0.2 ns
Group Delay Distortion 100kHz ≤ f ≤ 5MHz, inputs are 1V
P-P 10 ns
Interchannel Group Delay
Distortion Error
Outputs are 2V P-P 2 ns
Peak Signal to RMS Noise 100kHz ≤ f ≤ 5MHz, inputs are 1V
P-P
67 dB
Power-Supply Rejection Ratio f = 100kHz, 200mV P-P , input referred 43 dB
Output Impedance f = 5MHz 6 Ω
Enable Time
YIN = 1V, output settled to within 1% of the
final voltage, R
L = 150 Ω to GND
13 µs
Disable Time
YIN = 1V, output settled to within 1% of the
final voltage, R
L = 150 Ω to GND
1.1 µs
CROSSTALK
All Hostile Output Crosstalk f = 4.43MHz -71 dB
All Hostile Input Crosstalk
f = 4.43MHz, SHDN = GND,
input termination resistors are 75
Ω
-106 dB
MAX9512
Video Filter Amplifier with SmartSleep
and Y/C Mixer Circuit
_ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ _ 5
Note 1: All devices are 100% production tested at T A = +25°C. Specifications over temperature limits are guaranteed by design.
Note 2: Specified current is an average over time.
