MAX9512
Video Filter Amplifier with SmartSleep
and Y/C Mixer Circuit
16 _ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ _
16
15
14
13
12
11
10
9
1
2
3
4
5
6
7
8
SMARTSLEEP N.C.
V DD
COUT
YOUT
CVBSOUT1
CVBSOUT2
GND
N.C.
TOP VIEW
MAX9512
QSOP
CIN
V DD
N.C.
YIN
GND
N.C.
SHDN
+
Pin Configurations (continued) Chip Information
PROCESS: BiCMOS
CIN
YIN
COUT
YOUT
CVBSOUT1
SHDN
ACTIVE VIDEO
DETECT
SMARTSLEEP
CVBSOUT2
LPF
CONTROL
LOGIC
BUFFER
LOAD SENSE
6dB
LPF
BUFFER
LOAD SENSE
6dB
LOAD SENSE
6dB
LOAD SENSE
6dB
MAX9512
0
TO
50mV 300mV
TO
400mV
Block Diagrams (continued)
