Package Information
Ordering Information
Extended Type Number Package Remarks
U6820BM-FP SO16
13036
technical drawings
according to DIN
specifications
10.0
9.85
8.89
0.4
1.27
1.4
0.25
0.10
5.2
4.8
3.7
3.8
6.15
5.85
0.2
16 9
1 8
Package SO16
Dimensions in mm
