MACHINE DIMENSIONS
Footprint 1,702 mm x 1,676 mm (67” x 66”)
Weight (tank empty) 1,724 kg (3,800 lbs)
Height (with enclosure) 2,108 mm (83”)
Operating Weight (with water in tank) 2,177 kg (4,800 lbs)
WORK ENVELOPE
X-Y Cutting Travel* 610 mm x 610 mm (24” x 24”)
Z-Axis Travel* 102 mm (4”)
Table Size 711 mm x 711 mm (28” x 28”)
DRIVE DESCRIPTION
• Closed loop, digital drives
• Brushless servo motors
• Intelli-TRAX drive technology with
linear encoders in X-Axis
• Precise Motorized Z-Axis
STANDARD MODEL SPECIFICATIONS
Material Support Slats 4" x 1/8" Galvanized Steel
Maximum Supported Material Load 400 lbs/sq ft (1,950 kg/sq meter)
Electrical Requirements
3-Phase, 380-480 VAC ±10%,
50-60 Hz
Speed 2.5 m/min (100 ipm)
Accuracy of Motion at 70˚ F
Ballbar Circularity
(Over 12")
±15 microns
(±0.0006”)
Repeatability
±2.5 microns
(±0.0001”)
OPTIONAL ACCESSORIES
• EDM-Style Fixturing
• Catcher Tank Armor Plating
• Laser Feature Finder
• MAXJET 5i Nozzle Assembly
• Waterjet Brick Kit
• Material Holding Kit
*Optional accessories may reduce travel. Photos may show optional
accessories. For a complete list of accessories, contact an OMAX sales
representative. Pumps are built to meet UL and CE specifications. Contact
OMAX for detailed utility requirements.
ABOUT OMAX
OMAX is the global total solutions provider in advanced abrasive waterjet
systems. Our intuitive Intelli-MAX Software Suite simplifies programming and
reduces setup times, increasing your productivity. OMAX engineers continue
to innovate technology for waterjet machining, from proven 4th generation
pump designs to cutting edge drive systems with micron-level accuracy. With
the largest abrasive waterjet support network in the world, OMAX continues to
shape the future of waterjets.
To see how an OMAX JetMachining Center can save you time and money, call
or visit our website and request a free part analysis today.
