Technical specifications – Cobalt Digital COMPASS 9242 Analog Audio Distribution Amplifier with Remote Gain Control User Manual
Page 32
5-2
• Specifications
9242 Product Manual (V1.1)
Technical Specifications
This section provides the technical specifications for the 9242.
Table 5.1 9242 Technical Specifications
Category
Parameter
Specification
Analog Inputs
Number of Inputs
R2-1001: 2
RM20-9142-C/S: 1
Input Impedance
> 20k Ohm, balanced
Connector
WECO®
Maximum Input Level
+27.5dBu
Performance
Gain
-15dB to +15dB
Frequency Response
± 0.1dB from 20Hz to 20kHz
Noise
<-85dBu, 10-22kHz at unity gain
Harmonic Distortion
< 0.01%
Analog Outputs
Maximum Output Level
+27dBu
Output Impedance
60ohm balanced
Output Isolation
> 60dB
Power
Maximum Power Consumption
> 4.5W
