Before you begin, Static discharge, Unpacking – Cobalt Digital COMPASS 9242 Analog Audio Distribution Amplifier with Remote Gain Control User Manual
Page 16
2-2
• Installation
9242 Product Manual (V1.1)
Before You Begin
Static Discharge
Whenever handling the 9242 and other related equipment, please observe all static discharge
precautions as described in the following note:
ESD Susceptibility
— Static discharge can cause serious damage to sensitive
semiconductor devices. Avoid handling circuit boards in high static environments such as
carpeted areas and when synthetic fiber clothing is worn. Always exercise proper grounding
precautions when working on circuit boards and related equipment.
Unpacking
Unpack each 9242 you received from the shipping container, and ensure that all items are included. If
any items are missing or damaged, contact your sales representative or Cobalt Digital directly.
