9242 Product Manual (V1.1)

Introduction

1-5

Documentation Terms and Conventions

The following terms and conventions are used throughout this manual:

• “Board”, and “Card” refers to the 9242 card itself, including all components and

switches.

• “DashBoard” refers to the DashBoard Control System™.
• “20-Slot series frame” refers to 20-slot frames and any available options unless

otherwise noted.

• “Frame” refers to the 8321 or HPF-9000 20-Slot series frame that houses the 9242

card, as well as any openGear frames.

• “System” and “Video system” refers to the mix of interconnected production and

terminal equipment in which the 9242 operates.

• The “Operating Tips” and “Note” boxes are used throughout this manual to provide

additional user information.
