Page 15
9242 Product Manual (V1.1)
Installation
• 2-1
Installation
In This Chapter
This chapter provides instructions for installing the Rear Module(s) for the 9242, installing the card
into the frame, cabling details, and updating the card software.
The following topics are discussed:
• Before You Begin
• Installing the 9242
• Cabling for the 9242
• Software Upgrades for the 9242
