9242 Product Manual (V1.1)

DashBoard Menus

4-3

Settings Tab

Table 4.3 summarizes the Settings options available through DashBoard.

Table 4.3 Settings Menu Items

Tab Title

Items

Parameters

Description

Settings

Mode

Stereo DA (2x4)

ANLG In 1 outputs to ANLG Out 1-1, 1-
2, 1-3, and 1-4
ANLG In 2 outputs to ANLG Out 2-1, 2-
2, 2-3, and 2-4

Mono DA (1x8)

ANLG In 1 outputs to all eight ANLG
outputs

Stereo Sum

Card outputs a sum of ANLG In 1 and 2
to all eight ANLG outputs

STEREO Gain
Control

0 to 100

Adjusts the audio gain for all outputs

Left Trim
Control (dB)

-15 to +15

Specifies the coarse level gain
adjustment applied to ANLG In 1

Right Trim
Control (dB)

-15 to +15

Specifies the coarse level gain
adjustment applied to ANLG In 2
