2-6

Installation

9242 Product Manual (V1.1)

Software Upgrades for the 9242

The card can be upgraded in the field via the MFC-8300 series Network Controller card in your frame.

Note

— DashBoard version 3.0.0 or higher is required for this procedure.

To upgrade the software on a card

1. Contact Cobalt Digital Technical Support for the latest software version file.

2. Display the Device View of the card by double-clicking its status indicator in the Basic

Tree View.

3. From the Device View, click Upload to display the Select file for upload dialog.

4. Navigate to the *.bin upload file you wish to upload.

5. Click Open.

6. If you are upgrading a single card, click Finish. Proceed to step 8.

7. If you are upgrading multiple cards:

 Click Next > to display the Select Destination menu. This menu provides a list of

the compatible cards based on the card selected in step 3.

 Specify the card(s) to upload the file to by selecting the check box(es) for the cards

you wish to upload the file to.

 Verify that the card(s) you wish to upload the file to. The Error/Warning fields

indicate any errors, such as incompatible software or card type mismatch.

 Click Finish.

8. Monitor the upgrade.

 Monitor the upgrade progress bar displayed in DashBoard.

 The card(s) are automatically re-booted and temporarily taken offline during the re-

boot process. The process is complete once the status indicators for the Card State
and Connection fields return to their previous status.
