4-10 •••• Menus 9216-OE-DM User Manual •••• (V 1.1)
Alarm Enables Menus
Table 4.6 summarizes the Alarm Enables Menu options available in DashBoard.
Table 4.6 Alarms Menu Items
Menu Item Parameters Description
Checkbox selected*
Signal Status field reports a loss of
input
No Input
Checkbox unselected Disables the alarm
Checkbox selected*
Input Format field displays an alarm
when the input video is a format that
is not supported
Invalid Input
Checkbox unselected Disables the alarm
Checkbox selected*
Input Format field reports when the
frame rate is not the same as the
reference input
Incompatible Input
Checkbox unselected Disables the alarm
Checkbox selected*
Signal Status field reports if the
video input is asynchronous to the
reference
Non-Sync Input
Checkbox unselected Disables the alarm
Checkbox selected*
Reference Status field reports loss of
input conditions
No Reference
Checkbox unselected Disables the alarm
Checkbox selected*
Reference Format field reports when
the reference is a format that is not
supported
Video
Input &
Reference
Alarm
Invalid Reference
Checkbox unselected Disables the alarm
Checkbox selected*
Hardware Status field reports when
a rear module is not compatible with
the card
Hardware
Incompat Rear
Module
Checkbox unselected Disables the alarm
Checkbox selected*
Hardware Status field reports when
the temperature of the SFP module
is not in range (high/low)
Alarm on
Abnormal
Temperature
Checkbox unselected Disables the alarm
Checkbox selected*
Hardware Status field reports when
the power consumption of the SFP
module is not in range (high/low)
Optical
Module
Alarms
Alarm on
Abnormal Power
Checkbox unselected Disables the alarm
