937X-OM (V1.3) 9374-SERIES PRODUCT MANUAL 2-1
Chapter 2
Chapter 2
Installation and Setup
Overview
This chapter contains the following information:
• Installing the 9374-Series Card Into a Frame Slot (p. 2-1)
• Installing a Rear Module (p. 2-3)
• 9374-Series Analog Audio Output (p. 2-10)
• Setting Up 9374-Series Card Network Remote Control (p. 2-10)
Note: The 9374-Series cards are suitable for installation only in a 20-slot frame
(Cobalt
® PN HPF-9000 or 8321-CN or equivalent).
Installing the 9374-Series Card Into a Frame Slot
CAUTION
Heat and power distribution requirements within a frame may dictate specific
slot placement of cards. Cards with many heat-producing components should
be arranged to avoid areas of excess heat build-up, particularly in frames
using only convection cooling. The 9374-Series cards have a moderate power
dissipation (20 W max.). As such, avoiding placing the card adjacent to other
cards with similar dissipation values if possible.
CAUTION
This device contains semiconductor devices which are
susceptible to serious damage from Electrostatic
Discharge (ESD). ESD damage may not be immediately
apparent and can affect the long-term reliability of the
device.
Avoid handling circuit boards in high static environments
such as carpeted areas, and when wearing synthetic fiber
clothing. Always use proper ESD handling precautions
and equipment when working on circuit boards and
related equipment.
