9275-4C / 9275-8C User Manual •••• (V 1.2) Control and Monitoring •••• 4-5
Menu Item Parameters Description
Reference Status
Invalid Format -
Free Run
The following conditions are occurring:
• Card has detected an invalid b reference
format
• Input video is missing or invalid
• Card has switched to Free Run Mode
Input Format # Indicates the input video format
Reference Format # Indicates the reference video format
Output Format # Indicates the output video format
PCM
No Input
PCM-Silent
Non-PCM
Async
Signal
(Read-
only)
Embedded A udio
Status - Group #
Mixed
Indicates the presence of input
Setup Menus
Table 4.2 summarizes the Setup Menu options available in DashBoard for the 9275.
Table 4.2 Setup Menu Items
Menu Item Parameters Description
Frame 1*
Frame 2 Reference
Video
Selects the reference source
Checkbox selected*
Provides the shortest video delay
through the card. When using SD,
the delay is 7us. When using HD,
the delay is 1.5us.
Minimum Delay
Checkbox unselected
The total video delay through the
card will be the values above plus
half a video line
Black
Sets the output to Black in the event
of a loss of video input
Setup
Loss of Input
Blue
Sets the output to Blue in the event
of a loss of video input
