5. Specifications
38
PNEG-1702 ETL Listed GSI/FFI Portable Dryer Manual
All Stack Specifications (Continued)
Figure 5L
1. A 12" thick reinforced concrete foundation and 16" pedestal (min.) are required. See bulletin
FL-02-2 for details. 32" Thick pedestal required for heat reclaimer option (see bulletin FL-03-2
for details).
2. Approximate location of standard service platform shown. See bulletin SP-02-2 for details.
For information on optional catwalk, see bulletin CATH-01-5.
3. For safety cage information, refer to bulletin SC-01-2.
A
B
C
D
E
1
F
G
H
J
K
L
N
14'
23'-1-1/2"
2'-2"
14'-0"
4'-8"
16" Min.
11'-2"
4'-9-3/4"
0'-8"
8'-0"
3'-0"
23'-9-1/2"
6'-4"
18'
27'-1-1/2"
2'-2"
18'-0"
4'-8"
16" Min.
11'-2"
4'-9-3/4"
0'-8"
8'-0"
3'-0"
23'-9-1/2"
6'-4"
20'
29'-1-1/2"
2'-2"
20'-0"
4'-8"
16" Min.
11'-2"
4'-9-3/4"
0'-8"
8'-0"
3'-0"
23'-9-1/2"
6'-4"
22'
31'-1-1/2"
2'-2"
22'-0"
4'-8"
16" Min.
11'-2"
4'-9-3/4"
0'-8"
8'-0"
3'-0"
23'-9-1/2"
6'-4"
26'
35'-1-1/2"
2'-2"
26'-0"
4'-8"
16" Min.
11'-2"
4'-9-3/4"
0'-8"
8'-0"
3'-0"
23'-9-1/2"
6'-4"
H
G
L
D
E
B
C
A
J
K
N
F
14'-0"
SEE
NOTE 2
2'-8"-REAR SAFETY CAGE
SEE NOTE 3
7'-9"-SAFETY
PLATFORM
13'-0"-OPTIONAL
CATWALK
SEE
NOTE 1
