3. Fan/Heaters
PNEG-1403 Vision Series Model 1200 Portable Dryers
53
NG Supply Line Parts List
Ref #
Part #
Description
1214-1218
1220-1226
1
D08-0008
Valve, 1-1/2" NPT B-Cock Shut Off
1
1
1a
TFC-0093
Valve, 1" NPT Bronze Ball
1
1
2
D08-0009
Nipple, 1-1/2" Close SCH 40
3
3
2a
THH-4117
Nipple, 1" Close SCH 40
2
2
3
D08-0011
Elbow, 1-1/2" - 90° SCH 40
3
3
3a
THH-4115
Elbow, 1" x 90° SCH 40
1
1
4
HH-7070
Nipple, 1-1/2" x 54" SCH 40
1
4
HH-7076
Nipple, 1-1/2" x 60" SCH 40
1
5
D38-0001
Tee, 1-1/2" x 1-1/2" x 1" SCH 40
1
1
6
D01-0763
Nipple, 1-1/2" x 31-1/2" SCH 40
1
6
HH-7069
Nipple, 1-1/2" x 28" SCH 40
1
7
D08-0010
Union 1-1/2" Female SCH 40
1
1
8
HH-7068
Nipple, 1-1/2" x 24" SCH 40
1
1
9
031-1063-2
Shut Off Valve 1-1/2"
1
1
10
HH-7067
Nipple, 1-1/2" x 9" SCH 40
1
1
11
D08-0015
Strainer, 1-1/2" “Y” SCH 80
1
1
12
D67-0007
Plug 3/4" Square
1
1
13
D08-0007
Reducer, 1-1/2" x 1" Hex Bushing
1
1
14
007-1104-4
Nipple, Close 1"
2
2
15
007-1105-1
Union 1" Female SCH 40
2
2
16
033-1007-5
Gas Hose 1" NPT Male Both Ends
2
2
17
D31-0074
Gas Manifold Mounting Bracket
3
3
18
S-6643
Conduit Hanger 1-1/2"
3
3
19
D51-0045
Carrier Bracket, 1-1/2" Piping
1
1
