1. Main Structure Assembly
PNEG-1403 Vision Series Model 1200 Portable Dryers 11
Plenum (Inside) Screens and Meter Roll Upper Shield
Figure 1H Plenum Screens and Bulkheads (View from front end.)
19
This photograph was taken before the front plenum end
panel and outer screens were installed in order to get a
good view of the inside screens and bulkheads.
Plenum closure door. Two (2) different plenum closure doors are
there. The door shown in the photograph is the rear plenum
closure door and is the rear most plenum closure door, Ref #20
(just inside the rear access door), all others are Ref #20a.
NOTE: Ref #22 is the plenum closure door rear frame angle.
22
4
3
5
6
7
10
11
13 14
18
12 10
9
8
15
7
16
5
1
2 3
21
20a
20
