6. Sidedraw Accessory Instructions
46 PNEG-1400 WCL Commercial 4" Corrugation Externally Stiffened Grain Bin
1" Diameter Anchor Bolt Requirements for Sidedraw Systems
1" Diameter Anchor Bolt Requirements for Sidedraw Systems Installed in
WCL - 4" Corrugation Commercial Tanks
2 Post Tanks (2 Stiffener per Sidewall Sheet)
3 Post Tanks (3 Stiffener per Sidewall Sheet)
Nominal Tank Diameter Total Number of Anchors
36 24
39 26
42 28
48 32
54 36
60 40
72 48
75 50
78 52
90 60
105 70
Nominal Tank Diameter Total Number of Anchors
42 42
48 48
54 54
60 60
72 72
75 75
78 78
90 90
105 105
