Chapter 3 Eave Platform
Table 3-1 Top Dry Eave Platform Parts
Component Description
LS-6705 Platform Mounting Angle
LS-369 Brace Angle
LS-370 Support Angle
LS-373 Platform
LS-371 Platform Vertical Angle
LS-6621 Vertical Entrance Angle Extension
Ls-294 End Handrail Angle
LS-295 Front Handrail Angle
LS-6776 Safety Cage Hoop Adapter Angle
LS-6775 Safety Cage Extension Angle
S-275 5/16” x 3/4” YDP Grade 5 Hex Head Bin Bolt
S-277 5/16” x 1–1/4” YDP Grade 5 Hex Head Bin Bolt
S-396 5/16” Hex Nut
