PNEG-010 Vane Axial Fan 27
9. Parts List
12''-14'' Fan Parts
Ref #
Part #
Description
12" 0.75 HP 12'' 1 HP 14'' 1 HP
1 F-7359 F-7225 F-7230 VA Housing Assembly
2 - MTR-0145 MTR-0145 Motor 1 HP 1 PH 3400 RPM
2 FH-5579 - - Motor 1 HP 1 PH 3500 RPM
3 F-7124 F-7252 F-7301 GRP - VA Blade
4 F-7233 F-7233 F-7233 GRP - Safety Washer
5 F-7177 F-7177 F-7178 Grill Guard
6 S-3611 S-6606 S-6606 Flange Bolt 5/16"-18 x 3/4" ZN Grade 5
7 S-845 S-3611 S-3611 Flange Nut 5/16"-18 ZN YDP
8 S-6606 S-845 S-845 Flat Washer 5/16" USS SAE YDP Grade 2
