5. Fan Specifications
16 PNEG-010 Vane Axial Fan
Fan Electrical Specifications
Fan Horsepower 3/4 1
RPM 3450 3450
Phase 1 3 1 3
Volts 230 230 460 575 230 230 460 575
Full Load Amps 5.5 2.6 1.3 1 5.5 3 1.5 1.2
Minimum Wire Size Copper Wire Copper Wire
50' Run 14 14 14 14 14 14 14 14
100' Run 14 14 14 14 14 14 14 14
200' Run 12 14 14 14 12 14 14 14
300' Run 10 14 14 14 10 14 14 14
Minimum Wire Size Aluminum Wire Aluminum Wire
50' Run 14 14 14 14 14 14 14 14
100' Run 14 14 14 14 14 14 14 14
200' Run 10 14 14 14 10 14 14 14
300' Run 8 12 14 14 8 12 14 14
Fuse Size (Slow Blow) 15 10 5 5 15 10 5 5
Breaker Size 20 15 10 10 20 15 10 10
Fan Horsepower 1-1/2 3
RPM 3450 3450
Phase 1 3 1 3
Volts 230 230 460 575 230 230 460 575
Full Load Amps 7.5 4.6 2.3 1.8 15 7.4 3.7 3
Minimum Wire Size Copper Wire Copper Wire
50' Run 14 14 14 14 12 12 14 14
100' Run 12 14 14 14 10 12 12 12
200' Run 8 12 14 14 8 10 12 12
300' Run 6 10 12 12 6 8 10 10
Minimum Wire Size Aluminum Wire Aluminum Wire
50' Run 12 12 14 14 12 12 12 12
100' Run 10 12 12 14 8 10 12 12
200' Run 6 10 12 12 6 10 10 10
300' Run 4 10 12 12 4 8 10 10
Fuse Size (Slow Blow) 15 10 5 5 30 15 10 10
Breaker Size 20 15 10 10 40 20 15 15
