5. Fan Specifications
PNEG-010 Vane Axial Fan 17
Fan Horsepower 5 7
RPM 3450 3450
Phase 1 3 1 3
Volts 230 230 460 575 230 230 460 575
Full Load Amps 30 18 9 6.9 30 18 9 6.9
Minimum Wire Size Copper Wire Copper Wire
50' Run 10 10 12 12 10 10 12 12
100' Run 8 10 12 12 8 10 12 12
200' Run 4 8 10 12 4 8 10 12
300' Run 4 6 8 10 4 6 8 10
Minimum Wire Size Aluminum Wire Aluminum Wire
50' Run 8 8 12 12 8 8 12 12
100' Run 6 8 10 12 6 8 10 12
200' Run 3 6 10 10 3 6 10 10
300' Run 2 4 8 10 2 4 8 10
Fuse Size (Slow Blow) 40 25 15 15 40 25 15 15
Breaker Size 60 30 15 15 60 30 15 15
Fan Horsepower 10 15
RPM 3450 3450
Phase 1 3 1 3
Volts 230 230 460 575 230 230 460 575
Full Load Amps 47 25 13 9.6 57 32 16 14
Minimum Wire Size Copper Wire Copper Wire
50' Run 8 8 12 12 6 6 10 10
100' Run 6 6 10 12 4 4 10 10
200' Run 4 4 10 10 2 2 10 10
300' Run 2 2 8 8 0 0 8 10
Minimum Wire Size Aluminum Wire Aluminum Wire
50' Run 6 6 12 12 4 4 8 8
100' Run 4 4 10 10 2 2 8 8
200' Run 2 2 8 10 0 0 6 8
300' Run 0 0 6 8 0 0 4 6
Fuse Size (Slow Blow) 60 30 20 15 75 40 20 20
Breaker Size 80 40 20 20 100 60 30 20
