Portable Dryer Troubleshooting

27

Rear Discharge Mercury Switch

POSITIONED WITH LID CLOSED AND

SJOW 18/2 CORD POINTED TOWARDS

THE FRONT OF THE DRYER CONNECT

INSIDE METER ROLL BOX TO BROWN

AND ORANGE WIRES.

CONNECT TO SJOW CORD

INSIDE LRL BOX

LOOSEN SCREWS ON BRACKET

TO CHANGE SENSITIVITY

OF REAR DISCHARGE SWITCH

Wiring Reference
