5. 42'-60' Assembly Instructions
PNEG-1787 42'-135' “X” Series Sidewall Stair and Eave Platform
45
42'-60' Complete Form and Roof Stair Interaction
Figure 5J
shows interaction of sidewall stair, eave platform and roof stairs.
Figure 5K
